6 Colors Honor Gearless Stack Flexo Printing Machine for Packaging Films
Honor full servo stack flexo printing machine with independent servo drive, precise registration and stable operation. Space-saving design f
Honor full servo stack flexo printing machine with independent servo drive, precise registration and stable operation. Space-saving design for film & packaging Category: Film. Series: Honor Series.
Gearless Stack Structure
The gearless stack design eliminates conventional gear transmission, removing mechanical backlash and gear wear issues. It runs steadily with fewer failures, lowers regular maintenance expenses and downtime, and keeps reliable performance during long-hour continuous production.
Full Servo Drive System
Every printing and material handling unit is equipped with independent full servo motors. It ensures synchronous operation, quick response and stable running at rated speed. This advanced drive structure optimizes production efficiency and extends the overall service life of the machine
Universal Material Adaptability
This general-purpose flexo press supports a wide range of substrates including PE, PET, BOPP, PVC and different kinds of paper. It is applicable to food packaging, label, industrial film and various packaging products, helping you handle diverse orders with one single device
High Precision Printing Performance
It features accurate color registration up to ±0.2 mm for sharp and fine printing patterns. Compatible with water-based and alcohol-soluble eco-friendly inks and equipped with hot air drying system, it delivers consistent printing quality and effectively reduces defective products.
- • What this machine is designed to do
- • Which substrates and applications it fits
- • How its specifications compare with alternatives
- • What buyers should confirm before quotation
Compare against similar models
Compare this model side by side with nearby alternatives right on the page, without jumping to the compare view.
6 Colors Honor Gearless Stack Flexo Printing Machine for Packaging Films at a glance
Honor full servo stack flexo printing machine with independent servo drive, precise registration and stable operation. Space-saving design for film & packaging Width: 1160mm / 1200mm
| Material Type | Minimum Specification Maximum Specification Application Notes |
| LDPE (Low Density Polyethylene) | 50 µm 250 µm Ideal for FFS heavy-duty packaging films, general flexible packaging |
| HDPE (High Density Polyethylene) | 50 µm 150 µm Suitable for industrial packaging, FFS films for chemical & fertilizer products |
| PET (Polyethylene Terephthalate) | 50 µm 75 µm For high-barrier packaging, laminated films, label printing |
| PP (Polypropylene) | 50 µm 245 µm Widely used for FFS films, food packaging, industrial heavy-duty packaging |
| Paper | 40 g/m² 95 g/m² Suitable for paper packaging, labels, paper bags, coated paper printing |
| Material Type | Minimum Specification Maximum Specification Application Notes |
| LDPE (Low Density Polyethylene) | 50 µm 250 µm Ideal for FFS heavy-duty packaging films, general flexible packaging |
| HDPE (High Density Polyethylene) | 50 µm 150 µm Suitable for industrial packaging, FFS films for chemical & fertilizer products |
| PET (Polyethylene Terephthalate) | 50 µm 75 µm For high-barrier packaging, laminated films, label printing |
| PP (Polypropylene) | 50 µm 245 µm Widely used for FFS films, food packaging, industrial heavy-duty packaging |
| Paper | 40 g/m² 95 g/m² Suitable for paper packaging, labels, paper bags, coated paper printing |
| Parameter Category | Detailed Specification |
| Machine Model | Honor Series Full Servo Stack Flexo Printing Machine |
| Standard Configuration | 6 Colors; Customized color configuration available upon request |
| Max Material Feeding Width | 1200 mm |
| Max Effective Printing Width | 1160 mm |
| Standard Printing Repeat Length | 400 mm; Customizable range: 300 mm - 1000 mm |
| Compatible Printing Plate Thickness | 1.14 mm, 1.7 mm, 2.28 mm, 2.84 mm, 3.94 mm; Customized thickness available |
| Max Mechanical Speed | 220 m/min |
| Max Stable Printing Speed | 200 m/min (Depends on material thickness, printing pattern and ink type) |
| Color Registration Precision | ±0.2 mm |
| Standard Adaptable Materials | PE, PET, BOPP, PVC, LDPE, HDPE, PP, Paper |
| Core Application Scenarios | FFS heavy-duty packaging films, flexible packaging, industrial packaging, label printing, paper packaging |
| Drive System | Full Servo Independent Drive System (Electronic Line Shaft Control) |
| Heating Method | Electric Heating Drying System |
| Max Unwind Roll Diameter | Φ800 mm |
| Max Rewind Roll Diameter | Φ800 mm |
| Printing Plate Type | Photosensitive Resin Plate |
| Compatible Ink Type | Water-based Ink, Alcohol-soluble Environmentally Friendly Ink |
| Available Customizations | - Number of printing colors (up to 10+ colors) - Printing repeat length (300-1000mm) - Printing plate thickness - Material feeding width - Double-sided printing unit - Auto registration system - Other personalized configurations |
Honor full servo stack flexo printing machine with independent servo drive, precise registration and stable operation. Space-saving design for film & packaging Category: Film. Series: Honor Series.
6 Colors Honor Full Servo Stack Flexo Printing Machine for Packaging Films
Professional 6-color stack type flexo printing equipment with full servo gearless drive. This sleeve-type flexo press features automatic camera registration, suitable for flexible film and paper packaging production worldwide.
Core Advantages
Printing speed reaches 200 m/min, higher efficiency than conventional stack flexo printing machines
Precise register accuracy up to ±0.08 mm via camera auto-registration, product defect rate controlled below 0.3%
Full servo gearless drive structure eliminates gear wear, cuts annual maintenance costs by 70%
Quick-change sleeve design completes full 6-color job switch within 8 minutes to reduce downtime
Wide compatibility: works with BOPP, OPP, BOPET, PET, PE, CPP, PVC, PLA and various paper materials
Max material width up to 1600 mm, effective printing width 1160 mm for large-format production
This 6-color full servo stack flexo printing machine is designed for flexible packaging and paper packaging manufacturers. Equipped with independent servo motors and fully automatic camera registration system, it delivers stable high-speed performance compared with traditional stack flexo presses. Supported by energy-saving drying system and standard sleeve structure, the machine balances high efficiency and low operation cost. As a direct manufacturer, we deliver cost-effective and reliable equipment for global clients.
Certifications & Company Strength
With over 18 years of experience in R&D and production of flexo printing machinery, we have built a solid reputation as a reliable global supplier. All our equipment undergoes strict quality inspection and holds internationally recognized certifications.
Authorized Certifications: CE, ISO9001, SGS
Independent Intellectual Property: 32+ patents for gearless drive and servo control technology
Global Business Layout: Products exported to more than 40 countries, over 600 units running on site
Local After-sales Support: Service teams stationed in Europe, Southeast Asia and the Middle East
Machine Structure & Configuration
Every component is elaborately designed to reduce overall operating costs, simplify operation and ensure long-term stable operation.
Section | Main Components | Operational Benefits |
|---|---|---|
Unwinding Unit | Shaftless hydraulic chuck, automatic web guide, load cell tension controller | Max web width 1600 mm, accurate positioning prevents material deviation, stretching and wrinkling |
Printing Unit | 6 sets of independent servo drive, replaceable sleeves, enclosed doctor blade chamber, inter-color drying oven | Fast job replacement, 12% ink consumption reduction, anti-smudge high-speed printing |
Rewinding Unit | Taper tension rewinder, edge correction device, pneumatic shaft | Neat and flat finished rolls, easy for slitting, die-cutting and other post-processing |
The full servo gearless drive eliminates mechanical backlash effectively, delivering outstanding printing performance on various films and paper. The built-in visual registration system realizes fully automatic calibration, keeping every roll of finished products compliant with strict quality standards for packaging industry.
Machine Detail Gallery
Take a closer look at core components, control panel, printing groups and sleeve structure.
Technical Parameters
Item | Specification |
|---|---|
Model | Honor 6 Colors Stack Type |
Max Material Width | 1600 mm |
Printing Color | 6 Colors |
Max Printing Width | 1160 mm |
Mechanical Speed | 220 m/min |
Printing Speed | 200 m/min |
Applicable Materials | Paper, PE, PET, BOPP, PVC, OPP, BOPET, CPP, PLA |
Repeat Length | 400 mm - 800 mm |
Printing Cylinder & Anilox Roller | Sleeve type |
Max Unwind / Rewind Diameter | Φ800 mm |
Registration Precision | ±0.08 mm |
Heating Method | Electric heating |
Available Ink Type | Water base ink / Solvent ink |
Power Supply | 380V, 3PH, 50HZ/60HZ |
Optional Upgrade Modules
We provide diversified customized configurations to expand production capacity and create more profit points for your business.
Upgrade Option | Value & Advantage |
|---|---|
Additional Color Units (10+ Colors) | Produce multi-color packaging without adding extra equipment |
Auto Flying Splice | Realize non-stop production and eliminate roll changing downtime |
Cold Foil / Laminating Unit | Add inline finishing to enhance product added value |
UV Curing System | Support UV flexo printing for special materials |
Web Cleaning System | Remove surface dust to improve printing yield |
Automatic Ink Viscosity Control | Stable color performance and reduce ink waste |
Remote Maintenance & Diagnostics | Remote troubleshooting to shorten equipment downtime |
Standard Operating Workflow
The machine adopts fully digital control system, easy to operate and suitable for frequent order switching in modern packaging factories.
Recipe Storage & Recall: Save all production parameters for one-click loading of historical orders
Sleeve & Ink Replacement: Tool-free disassembly, fast switching between different production tasks
Automatic Tension Control: Keep film and paper stable during feeding and rewinding
One-touch Pre-registration: Complete color alignment automatically via high-definition camera
High-speed Intelligent Production: Real-time registration correction during formal operation
Finished Roll Unloading & Reset: Simple operation to start the next production cycle quickly
